HH Q6FX Analogue Mixing Console

The Q6FX is a compact 6-channel analogue mixing console designed and engineered in the UK. The Q6FX consists of 2 mono input channels with microphone inputs that utilise low-noise microphone preamps as well as a line input option on each channel. The mono input channels sit alongside 2 stereo line input channels perfect for electric pianos, synthesizers, drum machines, stereo audio from an external media player, or any other line-level sources.

Harnessing 4 banks of 3-band EQ and 16 high-quality DSP effects, the Q6FX gives you full control over your audio productions. 2in/2out USB functionality makes the Q6FX the perfect tool for recording performances, podcasts, and music production.

All of this combined with comprehensive monitoring, an auxiliary send with a stereo return, RCA in, global phantom power, pan on each channel, and a 4-point LED meter for your main mix all housed in a robust chassis make the Q6FX a complete portable powerhouse for traveling musicians and engineers alike. 

FEATURES

• 6 Channels
• 2 Mic inputs
• USB audio in/out
• Global phantom power

SPECIFICATIONS

• Mic Inputs: 2x XLR CH1-2
• EQ: 3 band (±15dB), Low 100Hz, Mid 2.5kHz, High 12kHz per channel
• Monitors: Stereo ¼” 6.3mm TRS Sockets
• FX Send: Mono 1/4" 6.3mm TRS
• Phones: Mono 1/4" 6.3mm TRS
• Effects: 16 reverb and delay effects with enable switch
• USB Audio: Inputs/Outputs: 2-in, 2-out, 16-bit, 24-bit, Sample Rate: 48kHz
• Line Inputs (Mono): 2x 1/4" 6.3mm TRS CH1-2
• Line Inputs (Stereo): 2x Stereo 1/4" 6.3mm TRS CH3-6
• Main Outputs: Balanced Stereo XLR
• Aux Send: Mono 1/4" 6.3mm TRS
• AC Power: Universal 100-240V ~ 50/60Hz (EIC C14 Socket, AC Cord included)
• Dimensions (HWD): 93.5 x 208.5 x 316mm (3.7" x 8.2" x 12.4")
• Weight: 2.8 Kg (6.2 lbs)
